Vermiculite board
Date:2020-09-17 16:55


Why Sunrise:

Modern aluminium production originates from the processes invented in the late 1880s. Once alumina is extracted from the ore bauxite, aluminium is produced through an electrolytic process in the smelter that is energy-intensive and primarily continuous.
An aluminium reduction cell consists primarily of a large, reinforced steel shell lined with layers of refractory insulation and barrier materials. Pot lining life generally extends 1500 to 3000 days but can be reduced if the lining fails prematurely through block cracking, lining erosion, poor operating conditions, etc. Spent pot linings must be removed and disposed.
So it is key to optimize energy use, prevent downtime and reduce costs of replacement parts.Sunrise develop innovative non-wetted structual insulation boards for primary aluminium production plants,which is based on our in-depth knowledge about today's challenges and needs of the primary aluminium production.

Brief Introduction:
Sunrise Vermiculite board is a magnesium silicate-based insulation board,made from forsterite & vermiculite & Special Binders etc,providing excellent thermal conductivity and high compressive strength characteristics combined with good thermal shock resistance and wear resistance up to 1000°C.
At operating temperatures, Sunsire non-wetted structural insulation board offers an optimum balance between excellent insulating properties and high strength that improves the thermo-mechanical stability of refractory systems in mineral treatment applications. This exhibits lining tightness and resistance to metal penetration. Also it reduces thermal shock and skull buildup, increasing productivity and operating efficiency.
In order to reduce energy cost and prolong pot lifetime, Sunrise develop innovative boards with excellent resistance to cryolite penetration and molten aluminium attack.
Sunrise board composition allows for easy cutting and shaping using ordinary wood-working tools.

Benefits from Sunrise Vermiculite board:
Excellent heat balance inside the electrolysis cells, due to excellent insulation properties;
Quick & Easy Installation;
Minimized specific energy consumption;
Reduced relining time and maintenance costs;
Increase equipment service life and shorten down time due to excellent resistance to cryolite and aluminium penetration;
Protect more vulnerable cathode bottom insulation beneath,as it promotes the formation of a protective glass layer in a similar way as the barrier bricks situated;
Non-wetted performance & Hydrophobic upto 300℃;
Outstanding strength & not fragile or spalling at high temperature;

Sunrise boards have been successfully used in Chinese Aluminium plants for years and now it is being widely used in an increasing number in overseas as well.
Sunrise board is ideal as back-up insulation in aluminium electrolysis cells, where it can be applied alone or as combi-boards (such as glued on calcium silicate boards) for easy installation.
